Spacedec Articulated Swing Monitor Arm - Wall Mount

$385.00

Collections: Monitor Arms, New products, Wall & Ceiling Mounted Monitor Arms

Full motion mount. Weight 1.5 - 9 kg. VESA 75x75 and 100x100

The SD-AT-DW-BK wall mount helps to conserve valuable desk space by mounting monitors on a wall. This leaves a monitor footprint of zero and creates an extremely productive workspace, free from clutter. Offers the ultimate in versatility. With three separate pivot/adjustment points, the user has full control over their monitor position in terms of height, reach, tilt and screen rotation. Height adjustment is effortless due to the monitor weight counter balancing gas strut mechanism which glides the monitor into position. Screen tilt and pan of up to 40° is also made simple with a ball joint integrated into the arm to position the screen for the optimum viewing angle. Combined, these features ensure that all adjustments can be made from a seated position. Ease of use clearly drives this mount making it an obvious choice for ergonomic excellence and user productivity.

Features

Supports mounting hole patterns: 75mm x 75mm;100mm x 100mm
Gas-strut mechanism allows for easy monitor adjustment from a seated position
Offers a wide range of movement via 3 pivot points
Ball joint mechanism allows 40 degrees of display adjustment in any direction from the vertical plane
Portrait to landscape rotation
External cable management
Arm maximum reach: 635 mm
Display height adjustment range: 460 mm
Comes with all mounting hardware
5 year warranty.

Specifications

Weight Capacity	9 kg
Tilt	20° of display adjustment in any direction
Screen Rotation	Landscape to portrait
Pan	20° of display adjustment in any direction
Horizontal levelling adjustment	460 mm
Display Compatibility	75x75, 100x100
Desk Mounting Type	Wall mount
Minimum distance from wall	141.9 mm
